# Generator Synchronization

Most of the electricity consumed today is produced by three phase synchronous  generator.Since a huge amount of electricity is consumed every day,AC power networks are generally made up of a large number of synchronous generator all operating in the same frequency.

When the power demand increase,additional generator are connected to the AC power network.Before connecting a three phase synchronous generator to an AC power network,the following conditions are to be observed :-

## What is generator synchronization?

### Important parameter

• Frequency ( Hz ) : The frequency of the voltages produced by the generator must be equal  to ac power network frequency.
• Voltage ( Volt ) : The value of voltages produced by the generator must be equal to the AC power network voltage.
• Phase Sequence : The phase sequence of the voltage must be same at that of the AC power network.
• Phase ( R,Y,B ) : The voltage produced by the generator must be in phase with the AC power network voltages

## Generator Synchronize precaution

A generator is said to be synchronized when all these condition are met.A synchronous generator must never be connected to an AC power network before verifying synchronization.

Connecting a non-synchronized generator to an AC power network could cause severe damages to the generator because of the high torque that would be applied to the generator shaft and huge currents that flow in the generator windings at connection.

Once a synchronous generator is connected to an AC power network,no current flows between the generator and the AC power network because they produce voltages having the same amplitude and phase.As a result,the generator supplier neither active or reactive power to AC power network.

In this case,the generator is said to be “floating” on the AC power network.Furthermore,its frequency can no longer be changed by adjusting the tourqe applied to the generator shaft.This is because the AC power network is so powerful that it imposes it own frequency.

However,adjusting the torque applied to the generator’s shaft allows changing the amount of active power that is exchanged between the generator an the ac power.Increasing or decreasing can make the torque increases or decrease the power active to ac power network.

The generator could even receive active power from the AC power network an thus operate as a synchronous motor if the torque applied to the generator’s shaft were decrease to zero

As in three phase synchronous motors,the amount of reactive power that is exchanged between a synchronous generator and the AC power network can be changed by adjusting the field of current.It usually adjusted so that no reactive power is exchanged between the generator and the AC power network.

So that the power factor of the generator is UNITY.This minimizes the line currents and allows the size of the conductor connecting the generator to the AC power network to be reduced to minimum.

1. haitham hashim says

I do not know how to thank you for your posts the task,thanks

2. kurniawan widi pramana says

thanks for sharing this useful and interesting topic, I really appreciate it..and now, you can solve my question related to generator in parallel with large AC system. And if I can conclude (and correct me if I wrong), the governor of generator will increase the torque, not the speed of the shaft, to increase the power delivered to system. And correct me if I wrong again, is it related to the equation that relates between Power, Torque, and Speed?
Power = Torque x Speed??

thank you,,,

• Tuhin Shubhra Das says

Well not going much into academical formulas and concepts. I am telling you just from my practical experience GOVERNORS ARE USED TO INCREASE THE SPEED OF THE SHAFT (RPM) OF THE GENERATOR (WHETHER DIESEL OR STEM TURBINE BASED IT DOSE NOT MATTER) AND HENCE TO RAISE OR LOWER THE ELECTRICAL FREQUENCY PRODUCED BY THE MACHINE

Jr Automation Engineer
JOHNS ELECTRIC Pvt. Ltd(SYSTEM HOUSE OF SIEMENS)
JAIPUR (INDIA)

• lemau says

HI Tuhin Shubhra Das,

3. Dear sir,
I would like to request you that we have 4 ac synchronous generator of 350 kw and generation voltage is,400vac step up to 11kv( TRansformer 11kv/400vac) and synchronized to grid. we synchronize only one generator at normal condition but rest other generator is not possible to synchronize. the voltage ,frequency are same to bus. when we switch on for synchronize the fuse blown of synchronizing circuit and also fuse blown of bus. pls reply soon.

• Ronald says

Check the phase orientation of your system, it is probably not parallel to the grid.

4. Zachary says

There is noticeably tons of dough to understand this.
I assume you made certain nice points in functions also.

5. Md.tofayelur Rahman says

could anybody tell me what is the symbol of diesel generator synchronous on single line diagram?
